- Number of axes : 9
- Number of spindles : 2
MAIN SPINDLE
- Max. bar diameter : 32 [mm]
- Max. machining length : 320 [mm]
- Spindle speeds : 8.000 [rpm]
- Spindle power : 3.7 / 5.5 [kW]
- C axis indexing precision : 0,001 [°]
COUNTER-SPINDLE
- Max. bar diameter : 32 [mm]
- Spindle speeds : 8.000 [rpm]
- Spindle power : 2.2 / 3.7 [kW]
- C axis indexing precision : 0,001 [°]
GUIDE BUSH HOLDER 1
- Number of positions : 9
- Number of motorized positions : 4
- Live tools speed : 6.000 (T01-T02-T03) / 4000 (T04) [rpm]
- Live tools power : 1 [kW]
- X/Y stroke : 142 / 348 [mm]
GUIDE BUSH HOLDER 2
- Number of positions : 3
GUIDE BUSH HOLDER WITH AXIS B
- Number of positions : 8
- Number of motorized positions : 4
- Live tools speed : 5.000 [rpm]
- Live tools power : 1 [kW]
- Stroke axis B : 0 - 135 [°]
SECONDARY OPERATION
- Number of positions : 8
- Number of motorized positions : 4
- Live tools speed : 6.000 [rpm]
- Live tools power : 1 [kW]
END ATTACHMENT
- Number of positions : 2
- Number of motorized positions : 2
- Live tools speed : 8000 [rpm]
- Live tools power : 1 [kW]
POWER SUPPLY
- Total installed power : 21 [kVA]
WEIGHT & DIMENSIONS
- Machine floor space : 2.150 x 1.280 [mm]
- Machine height : 2.010 [mm]
- Machine weight : 3.600 [kg]
MACHINE HOURS
- Number of hours under power : 37855 [h]
- Number of working hours : 9578 [h]
Equipment
- CNC : Fanuc 31i-B5
- Interface : RS232 / PCMCIA / RJ45 / USB
- Rotating guide bush
- Parts catcher
- Ejection of workpiece
- Parts conveying strip
- Chips conveyor
- Coolant tank : MULLER COMBILOOP CL2
* with high-pressure pump : 100 [bars]
- Bar loader : IEMCA BOSS 338 HD / 32 LL
- Electric transformer
