- Number of axes : 10
- Number of spindles : 2
MAIN SPINDLE
- Max. bar diameter : 16 [mm]
- Max. machining length : 184 [mm]
- Spindle speeds : 10.000 [rpm]
- C axis indexing precision : 0.1 [°]
COUNTER-SPINDLE
- Max. bar diameter : 16 [mm]
- Spindle speeds : 10.000 [rpm]
- C axis indexing precision : 0.1 [°]
GUIDE BUSH HOLDER 1
- Number of positions : 5
- Number of motorized positions : 3
- Live tools speed : 8.000 [rpm]
GUIDE BUSH HOLDER 2
- Number of positions : 5
- Number of motorized positions : 3
- Live tools speed : 8.000 [rpm]
END ATTACHMENT
- Number of positions : 4
- Number of motorized positions : 4
- Live tools speed : 8.000 [rpm]
SECONDARY OPERATION
- Number of positions : 6
- Number of motorized positions : 3
- Live tools speed : 8.000 [rpm]
POWER SUPPLY
- Supply voltage : 400 [V]
- Total installed power : 14 [kVA]
MACHINE HOURS
- Number of working hours : 48.249 [h]
Equipment
- CNC : Fanuc PNC DECO
- Rotating tool motor on : S2, S3, S5,S6
- Rotating guide bush
- Parts catcher
- Coolant tank
* with high-pressure pump
- Bar loader : IEMCA GENIUS 118 / 32LL
- Cooling unit : MARKSA CSW 200
- Fire extinguisher *
NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.
- Number of turning tool holders : 3
