KAFO CV-9A 3 axis

Milling Vertical machining center

PDF datasheet to download:

Brand: KAFO

Model: CV-9A

Year: 2013

Serial: 262135

Ask Price

Caracteristics

- Number of axes : 3
MILLING SPINDLE
- Tool holder type : BT40
- Spindle power : 15 [kW]
- Spindle speeds : 12000 [rpm]
- Number of spindle hours : 0 [h]
LINEAR AXES
- Travels on X/Y/Z axes : 900/600/600 [mm]
- Rapid traverses rates (X/Y/Z) : 48 [m/min]
- Distance table / spindle nose (min./max.) : 100-700 [mm]
TOOL CHANGER
- Auto. Tool Changer type : Bras chargeur
- Tool magazine capacity : 40
- Tool exchange time : 3.8 [sec]
TABLE
- Table dimensions : 1000 X 600 [mm]
- Maximum weight upon table : 650 [kg]
POWER SUPPLY
- Supply voltage : 400 [V]
- Total installed power : 20 [kW]
WEIGHT & DIMENSIONS
- Machine floor space : 3500 X 2400 [mm]
- Machine height : 3000 [mm]
- Machine weight : 7000 [kg]

Equipment

- CNC : Fanuc Oi MD
- Interface : RS232 / USB
- Interactive programming : Manual guide Oi,10,4
- Electronic handwheel
- Rigid tapping
- 3 colors status lamp
- Coolant tank
* with high-pressure pump : 20 [bars]
* with paper filtering unit
- Coolant through spindle
- Micro-lubrification coolant
- Chips conveyor
