STUDER RM 250

Name: Cylindrical grinder STUDER RM 250
Brand: STUDER
Availability: InStock

Grinding / sharpening / lapping / deburring / polishing Cylindrical grinder

15310

PDF datasheet to download:

Brand: STUDER

Model: RM 250

Year:

Serial:

15310

STUDER RM 250

Grinding / sharpening / lapping / deburring / polishing Cylindrical grinder

PDF datasheet to download:

Brand: STUDER

Model: RM 250

Year:

Serial:

Ask Price

Caracteristics

- center height : 60 [mm]
- Distance between centers : 250 [mm]
- Between centres false table : 80 [mm]
- Maxi table traverse : 250 [mm]
- Table orientation : 7 [°]
- Table speed : 0.2-0.3 [m/min]
- Grinding wheel diameter : 250 [mm]
- Grinding wheel width : 10-25 [mm]
- Grinding wheel boring : 76 [mm]
- Grinding wheel speed : 2150 -2850 [rpm]
- Plunging speed : 0.5-26 [mm/sec]
- Radius maxi plunging : 0.24 [mm]
- Rapid return : 22 [mm]
- Fixed headstock taper : MT1
- Part speed : 200-1200 [rpm]
- Spindle : W20
- Maxi clearance for the collet : 14.5 [mm]
- 3 jaws chuck diameter : 70/80 [mm]
- Max. tightening diameter : 90 [mm]
