- distance between centers : 600 [mm]
- centers height : 125 [mm]
- table swivelling : 11 [°]
WHEELHEAD
- dimensions left wheel : 400 x 50 x 127 [mm]
- dimensions right wheel : 225 x 20 x 76,2 [mm]
- motor power : 3 [kW]
- spindle speeds : 1500 / 1700 / 2200 [rpm]
- swivelling : 270 [°]
- travel in X : 260 [mm]
WORKHEAD
- attachment : CM5
- swivelling : +120 / -30 [°]
- infinitely variable speeds : 5 - 500 [rpm]
- motor power : 2,4 [kW]
- travel in Z : 900 [mm]
TAILSTOCK
- attachment : CM3
- quill travel : 30 [mm]
DIMENSIONS
- floor space : 3.200 x 2.100 [mm]
- height : 1670 [mm]
- weight : 2.200 [kg]
ELECTRICS
- voltage : 380 [V]
- frequency : 50 [Hz]
- installed power : 6,5 [kW]
Equipment
- 2 axes display : ELESTA Visulesta IIE
- CM3 tailstock
* with hydraulic retractation through pedal
* with fine adjustment of concentricity
* with fix wheel dresser
- coolant tank with pump
- paper filtering unit : BEDA 1030
- 3 jaws chuck RÖHM Ø : 160 [mm]
- 2 benches of accessories
